TinkrPostr: Schematic Symbols Reference Poster (PRINT)

What's in the poster?

Sources / Ground Symbols - Resistor Symbols - Capacitor Symbols - Inductor Symbols - Meter Symbols - Electromechanical Devices - Diode Symbols - Transistor Symbols - Logic Symbols - Miscellaneous Symbols

Closer Look

Specifications

All posters follow the following specifications.

• Size: 18" x 24"
• Printed poster: Paper made of fibrous material and light absorbing matte finish

Why Get TinkrPostrs?

• Quick Reference: Access and recall bits of information at a quick glance.
• Inspire Creativity: Beautiful poster designed to spark creativity, imagination and encourage learning.
• Support Education: Perfect for teachers looking to enhance their classroom environment or professionals seeking to add a touch of inspiration to their learning spaces.

Licensing

License under CC BY-NC-SA 4.0. You are free to share, copy, redistribute the material, adapt, remix, transform, and build upon the material in any medium or format for non-commercial use. See license details for more info.
